Delete an 802.1Q-Based VLAN
You can delete an 802.1Q-based VLAN that you no longer need.You cannot delete the default VLAN.You
cannot delete a VLAN that is in use as the PVID for a port either.You must first remove the VLAN as the
PVID for the port before you can delete the VLAN.
If you deactivate the 802.1Q-based VLAN mode, all port-based VLANs are deleted.Note
To delete an 802.1Q-based VLAN:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SWITCHING.
The QOS page displays.
5. From the menu on the left, select VLAN.
The VLAN page displays.
By default, the Port Configuration tab is selected and the 802.1Q PORT CONFIGURATIONS pane
displays.
6. Click the VLAN Configuration tab.
The 802.1Q VLAN CONFIGURATIONS pane displays.
7. In the row for the VLAN that you want to delete, click the down arrow.
8. Click the DELETE button.
Your settings are saved. The VLAN is deleted.
Deactivate the Port-Based or 802.1Q-Based VLAN Mode
and Delete All VLANs
If you activated the port-based VLAN mode or the 802.1Q-based VLAN mode, you can deactivate either
VLAN mode and delete all VLANs.
To deactivate the port-based VLAN mode or 802.1Q-based VLAN mode and delete all VLANs:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
Use VLANS for Traffic Segmentation
50
Nighthawk Pro Gaming SX10 Switch Model GS810EMX
