The QOS page displays.
5. From the menu on the left, select VLAN.
The VLAN page displays.
6. In the PORT BASED VLAN section, click the ACTIVATE MODE button.
A pop-up window opens, informing you that the current VLAN settings will be lost.
7. Click the CONTINUE button.
Your settings are saved and the pop-up window closes. By default, VLAN 1 is added.
Create a Port-Based VLAN
A port-based VLAN configuration lets you assign ports on the switch to a VLAN.The number of VLANs is
limited to the number of ports on the switch. In a basic port-based VLAN configuration, ports with the same
VLAN ID are placed into the same VLAN. One port can be a member of multiple VLANs.
By default, all ports are members of VLAN 1.
To create a port-based VLAN:
1. Open a web browser from a computer that is connected to the same network as the switch or to the
switch directly through an Ethernet cable.
2. Enter the IP address that is assigned to the switch.
The login page displays.
3. Enter the switch password.
The default password is password. The password is case-sensitive.
The HOME page displays.
4. From the menu at the top of the page, select SWITCHING.
The QOS page displays.
5. From the menu on the left, select VLAN.
The VLAN page displays.
If you did not yet activate the port-based VLAN mode, see Activate the Port-Based VLAN Mode on page
42.
6. In the PORT BASED VLAN section, click the ADD VLAN button.
7. Specify the settings for the new VLAN:
• VLAN Name. Enter a name from 1 to 20 characters.
• VLAN ID. Enter a number from 1 to 10.
• Ports. Select the ports that you want to include in the VLAN through a combination of the following
actions:
Use VLANS for Traffic Segmentation
43
Nighthawk Pro Gaming SX10 Switch Model GS810EMX
