2.
Specifications
2-1.
Controller Specifications
2-1-1.
General Specifications
Item Specifications
Model VS-5E,
VS-5ED,
VS-5EX VS-5E-1,
VS-5ED-1,
VS-5EX-1
Construction Built-in type (mounting on panel face is also possible using a special fixture)
Input power voltage 100VAC
50/60Hz 24VDC
Permissible voltage
fluctuation
85V - 132VAC 21.6V - 30VDC
Power consumption 20VA or less 8VA or less
Insulation resistance
20M
Ω
or more between AC power terminals & ground
Withstand voltage
1500VAC, 60Hz,for 1 minute between AC
power terminals and ground
500VAC, 60Hz, for 1 minute between DC
power terminals and ground
Ambient temperature
0 - 55
℃
Ambient humidity 20 - 90%RH (no condensation)
Ambient atmosphere Free of corrosive gases, excessive dust, etc.
Ground Must be securely grounded
Weight Approx. 0.7kg
Note: The VS-5E-1, VS-5ED-1, and VS-5EX-1 operation panel inscriptions appear in both in English and Japanese.
2-1-2.
Performance Specifications
Item Specifications
Model VS-5E, VS-5E-1 VS-5ED, VS-5ED-1 VS-5EX, VS-5EX-1
Position detection format Absolute detection
Number of position
detection devices
1
ON/OFF position setting format Numeric key input or TEACH setting
Minimum setting unit
0.5゜
Number of multi-dogs Max. of 10 per switch output
Response rotation speed Max. 900 rpm (when ON/OFF zone is 1 degree)
Number of Programs 1 8 16 32
Number of switch outputs 24 24 40 24
Setting value memory EEP-ROM
Switch No., multi-dog No., current position value, setting value, operation error, initial No.
Display
Program No.
Error displays Memory error, sensor error, no setting, setting impossible
-Protected switch (for switch No.1-10 outputs)
-Timing pulse output (60, 180, 360 pulse/revolution)
-Setting change during operation
-Serial communication External origin set function
Auxiliary functions
Current position output
●A-6●
