9-2.
Designating The Switch Output Settings
9-2-1.
Setting The Switch Outputs by The TEACH Function
Set the key-switch to the TEACH position.
Select the desired Program No.
１
 PROGRAM
Select the desired switch No.
１ ０１
      SWITCH
Press the POSITION key.
The current position value will be displayed.
Move the machine to the desired ON position.
The current position value will be displayed.
 POSITION
Press the [SET] key.
The ON position setting is registered.
１
１１
１
２
２２
２
３
３３
３
６
６６
６
SET
SETSET
SET
┼
─
５
５５
５
┼
─
１２５
４
４４
４
┼
─
┼
─
NOR. CUR. SET ON OFF
SENSOR
SET
TEACH
CLEAR
INIT
RUN
●C-14●
