2-2.
Sensor Specifications
Model Code VRE-P062 VRE-P028
Outside Dimensions mm 62 dia. x 71.5 long 28 dia. x 35 long
Mass kg 1.2 0.25
Starting Torque N-m 4.9 x 10
-2
or less (with oil seal) 1.5 x 10
-3
or less (without oil seal)
Moment Inertia kg-m
2
6.4 x 10
-6
9.3 x 10
-8
Radial N 98 15 Permissible Input
Shaft Load
Thrust N 49 9.8
Mechanical permissible
Input Shaft Speed
r/min 3,600 6,000
Resistance to Vibration 20G, 2,000 Hz, up/down 4h, forward/back 2h, conforms to JIS D1601 standard
standard 2m Cable Length
option Extensible up to 100 m
Storage
℃
-30 to +90 Ambient
Temperatures
Operating
℃
-20 to +60
2-3.
Extension Cable Specifications
Cable Type STANDARD ROBOTIC
3P-S-0102-[ ] 3P-RBT-0102-[ ] Model Code
Specify an overall length of cable required in [ ]
Ambient Operating
Temperature Range
-5 to +60℃
Construction 3-pair (6-core)
Cross-sectional Area of Wire 0.2mm
2
Color of Sheath Grey Black
Advantages Standard cable Usable with moving machine member
thanks to excellent flexibility.
2, 3, 5, 8, 10, 13, 15, 20, 30, 50, 100
meters
2, 3, 5, 8, 10, 13, 15, 20, 30, 50, 100
meters
Available Length of Cable
Assembly
6.5, 9.8, 16.4, 26.2, 32.8, 42.6, 49.2, 65,
98, 164, 328 ft.
6.5, 9.8, 16.4, 26.2, 32.8, 42.6, 49.2, 65,
98, 164, 328 ft.
●A-8●
