9-1-6.
Current Position Value Setting
This setting operation is the equivalent of the “origin set” operation. However, with this procedure, there’s
no need to move the machine to the origin point position.
Instead, the current position value for a given position is designate by a numeric input.
Verify that the Absocoder sensor is connected.
If not connected, a “sensor error” will occur, and setting will
be impossible.
Set the key-switch to the INIT position.
Designate Initial No. “98”.
９８
SWITCH
Use the POSITION keys to designate the desired current position value.
Permissible setting range: 000 to 359.5
Press the [SET] key.
The designated current position value will then be displayed as
the value of the current STOP position.
(This completes the initial setting operations.)
２
２２
２
３
３３
３
┼
─
５
５５
５
SET
SETSET
SET
４
４４
４
┼
─
┼
─
１
１１
１
SET
TEACH
CLEAR
INIT
RUN
