Model
*1
3Z4S-LE
VS-TCH4
-65££££
3Z4S-LE
VS-TCH4
-1
10££££
Optical magnification (±5 %) 4.0x
Field of
view
(±5%)
(V x H)
(mm)
FH-SC/SM 1/3 inch equivalent 1.2 x 0.9
FH-S£05R
1/2.5 inch equiva-
lent
1.43 x 1.07
FZ-SC/S 1/3 inch equivalent 1.2 x 0.9
FZ-SC2M/S2M 1/1.8 inch equiva-
lent
1.8 x 1.3
FZ-SC5M£/S5M£
2/3 inch equivalent 2.1 x 1.8
WD (mm)
*2
65 110.8
Effective FNO 17.91 22.2
Depth of field (mm)
*3
0.09 0.11
Resolution (μm)
*4
3 3.73
TV distortion 0.02 % 0.03 %
Maximum sensor size 2/3 inch
*1.
Insert the shape into ££££ in the model number as follows.
Straight: -O
Coaxial: CO-O
*2. The working distance is the distance from the end of the lens to the sensor.
*3. The depth of field is calculated using a permissible circle of confusion diameter of 0.04 mm.
*4. The resolution is calculated using a wavelength of 550 nm.
Precautions for Correct Use
1. Fixing the lens or other reinforcement may be required depending on the installation angle
or operating environment (vibration/shock). When fixing the lens, insulate the lens from the
fixture.
2. The above specifications are values calculated from the optical design and can vary de-
pending on installation conditions.
3-4-12
High-resolution Telecentric Lens for C-mount Lens for 1.1-inch
Image Sensor (VS-TEV Series)
FH-S£X12, FH-S£21R, FH-S£04, and FH-S£02 are recommended.
Specification
Model
3Z4S-LE
VS-TEV0305
3Z4S-LE
VS-TEV05075
3Z4S-LE
VS-TEV07510
Optical magnification 0.3x 0.5x 0.5x 0.75x 0.75xx 1.0x
3 Configuration
3-67
FH Series Vision System Hardware Setup Manual (Z366-E1)
3-4 Lens
3
3-4-12 High-resolution Telecentric Lens for C-mount Lens for 1.1-inch Image Sensor (VS-TEV Series)
