Omron FH-L550 Setup Manual

1-1
Sensor Controller
First, please check to see whether the package has all the necessary Sensor Controller parts.
1-1-1
FH-1£££/FH-2£££/FH-3£££/FH-5£££ Series
• Sensor Controller: 1
FH-1£££/FH-2£££/FH-3£££/FH-5£££: 1
•
Instruction sheet: 1
• Instruction Installation Manual for FH series: 1
• General Compliance Information and Instructions for EU: 1
• Membership registration: 1
• Power source: 1 (male)
FH-XCN: 1
• Ferrite core for camera cable: 2
1-1-2
FH-1£££-10/FH-2£££-10/FH-3£££-10/FH-5£££-10 Series
• Sensor Controller: 1
FH-1£££-10/FH-2£££-10/FH-3£££-10/FH-5£££-10: 1
•
Instruction sheet: 1
• Instruction Installation Manual for FH series: 1
• General Compliance Information and Instructions for EU: 1
• Membership registration: 1
• Power source: 1 (male)
FH-XCN: 1
• Ferrite core for camera cable: 4
1 Confirm the Package
1-2
FH Series Vision System Hardware Setup Manual (Z366-E1)

Omron FH-L550 Specifications

General

Brand	Omron
Model	FH-L550
Category	Machine Vision Systems
Language	English
