3-2-3
Digital CCD Camera: FZ-S Camera Series
Specification
Model FZ-S FZ-SC FZ-S2M FZ-SC2M FZ-S5M2 FZ-SC5M2
Image elements Interline transfer reading all
pixels, CCD image ele-
ments (1/3-inch equivalent)
Interline transfer reading all
pixels, CCD image ele-
ments (1/1.8-inch equiva-
lent)
Interline transfer reading all
pixels, CCD image ele-
ments (2/3-inch equivalent)
Color/Monochrome Mono-
chrome
Color Mono-
chrome
Color Mono-
chrome
Color
Effective pixels 640 (H) x 480 (V) 1600 (H) x 1200 (V) 2448 (H) x 2044 (V)
Imaging area H x V
(opposing corner)
4.8 x 3.6 (6 mm) 7.1 x 5.4 (8.9 mm) 8.4 x 7.1 (11 mm)
Pixel size 7.4 (μm) x 7.4 (μm) 4.4 (μm) x 4.4 (μm) 3.45 (μm) x 3.45 (μm)
Shutter function Electronic shutter:
Shutter speeds can be set from 20 μ
s to 100 ms.
Partial function 12 to 480 lines 12 to 1200 lines 12 to 2044 lines
Frame rate (Image
Acquisition T
ime
*1
)
80 fps (12.5 ms) 30 fps (33.3 ms) 16 fps (62.5 ms)
Lens mounting C mount
Field of vision, in-
stallation distance
Selecting a lens according to the field of vision and installation distance
Ambient tempera-
ture range
Operating: 0 to +50°C, Stor-
age: -25 to +65°C (with no
icing or condensation)
Operating: 0 to +40°C, Stor-
age: -25 to +65°C (with no
icing or condensation)
Operating: 0 to +40°C, Stor-
age: -25 to +65°C (with no
icing or condensation)
Ambient humidity
range
Operating and Storage: 35 to 85% (with no condensation)
Weight Approx. 55g Approx. 76g Approx. 140g
Accessories
• Instruction Sheet • Instruction Sheet
• General Compliance In-
formation and Instruc-
tions for EU
*1. This image acquisition time does not include the image conversion processing time of the sensor controller.
Dimensions
3 Configuration
3-30
FH Series Vision System Hardware Setup Manual (Z366-E1)
