Installing the Smart Camera
5-2-1
How to Connect
Precautions for Safe Use
Installation
• Be sure to turn OFF the power of the Smart Camera itself and any peripheral devices con-
nected to it when doing any of the following. Failing to do so can cause equipment malfunc-
tion and damage.
- When connecting wires or cables
- When connecting or disconnecting any connectors
- When connecting or disconnecting lighting modules
- When connecting or disconnecting lens modules
• Tighten the mounting screws securely with the specified torque and in the order described in
this manual.
• Be sure to attach the connector cap when removing the cable. Failure to do so may result in
malfunction or equipment damage due to foreign matter getting in to the connector.
• If there are any locking mechanisms in place, make sure to check that they are securely in a
locked position before using.
• Do not apply torsion stress to the cable. It may damage the cable.
• Secure the minimum bending radius of the cable. Otherwise the cable may be damaged.
Precautions for Correct Use
For good ventilation, provide a clearance of 30 mm or more
• Do not let the ambient temperature exceed 40℃.
Provide a forced-air fan cooling or air conditioning if the ambient temperature is near 40℃ or
higher so that the ambient temperature never exceeds 40℃.
5 Installation
5 - 14
FHV Series Smart Camera Setup Manual (Z408-E1)
