3-2-2
Ethernet Cables
Specifications
• Ethernet Cables (Straight)
Item FHV-VNB 2M FHV-VNB 3M FHV-VNB 5M
FHV-VNB
10M
FHV-VNB
20M
Cable length 2 m 3 m 5 m 10 m 20 m
Cable type Bending resistance cable
Connector type Straight connector
Outer diameter 7.2+0.3 mm dia.
Min. bending radius Fixed use: 35 mm, Sliding use: 70 mm
Usage
environment
Ambient
temperature
range
Operating: -40 to +80℃, Storage: -40 to +100℃ (with no icing or condensation)
Ambient
humidity
range
Operating & Storage: 0 to 93%RH (With no condensation)
Ambient
atmosphere
No corrosive gases
Vibration
tolerance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration direc-
tion: X/Y/Z, Sweep time: 8 minute/count, Sweep count: 10
Shock
resistance
Impact force: 150 m/s
2
, Test direction: 6 directions, three time each (up/down,
front/behind, left/right)
Material Mold part: Nylon, Thermoplastic polyurethane, Sheath part: Polyurethane
Weight Approx. 210 g Approx. 240 g Approx. 310 g Approx. 380 g Approx. 730 g
• Ethernet cables (Right angle)
Item
FHV-VNLB
2M
FHV-VNLB
3M
FHV-VNLB
5M
FHV-VNLB
10M
FHV-VNLB
20M
Cable length 2 m 3 m 5 m 10 m 20 m
Cable type Bending resistance cable
Connector type Right angle connector
Outer diameter 7.2+0.3 mm dia.
Min. bending radius Fixed use: 35 mm, Sliding use: 70 mm
Usage
environment
Ambient
temperature
range
Operating: -40 to +80℃, Storage: -40 to +100℃ (with no icing or condensation)
Ambient
humidity
range
Operating & Storage: 0 to 93%RH (With no condensation)
Ambient
atmosphere
No corrosive gases
Vibration
tolerance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration direc-
tion: X/Y/Z, Sweep time: 8 minute/count, Sweep count: 10
Shock
resistance
Impact force: 150 m/s
2
, Test direction: 6 directions, three time each (up/down,
front/behind, left/right)
Material Mold part: Nylon, Thermoplastic polyurethane, Sheath part: Polyurethane
3 Configuration
3 - 13
FHV Series Smart Camera Setup Manual (Z408-E1)
3-2 Cables
3
3-2-2 Ethernet Cables
To Next Page
