Omron FHV Series User Manual

3-2
Cables
3-2-1
I/O Cables
Specifications
• I/O cables (Straight)
Item FHV-VDB 2M FHV-VDB 3M FHV-VDB 5M
FHV-VDB
10M
FHV-VDB
20M
Cable length 2 m 3 m 5 m 10 m 20 m
Cable type Bending resistance cable
Connector type Straight connector
Size Power line AWG21
Others AWG26
Outer diameter 9.0±0.3 mm dia.
Min. bending radius Fixed use: 54 mm, Sliding use: 72 mm
Usage
environment
Ambient
temperature
range
Operating: -30 to +80℃, Storage: -30 to +100℃ (with no icing or condensation)
Ambient
humidity
range
Operating & Storage: 0 to 93%RH (With no condensation)
Ambient
atmosphere
No corrosive gases
Vibration
tolerance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.35 mm, Vibration direc-
tion: X/Y/Z, Sweep time: 8 minute/count, Sweep count: 10
Shock resist-
ance
Impact force: 150 m/s
2
, Test direction: 6 directions, three time each (up/down,
front/behind, left/right)
Material Mold part: Nylon, Thermoplastic polyurethane, Sheath part: PVC
Weight Approx. 270 g Approx. 390 g Approx. 620 g Approx. 1200
g
Approx. 2350
g
• I/O cables (Right angle)
Item
FHV-VDLB
2M
FHV-VDLB
3M
FHV-VDLB
5M
FHV-VDLB
10M
FHV-VDLB
20M
Cable length 2 m 3 m 5 m 10 m 20 m
Cable type Bending resistance cable
Connector type Right angle connector
Size Power line AWG21
Others AWG26
Outer diameter 9.0±0.3 mm dia.
Min. bending radius Fixed use: 54 mm, Sliding use: 72 mm
3 Configuration
3 - 10
FHV Series Smart Camera Setup Manual (Z408-E1)
