Lens Modules
3-3-1
Specifications
Item
FHV-LEM-
S06 S09 S12 S16 S25
Focal length 6 mm 9 mm 12 mm 16 mm 25 mm
Installation distance 59 to 1000
mm
60 to 1000
mm
60 to 1000
mm
110 to 2000
mm
188 to 2000
mm
Usage environment
Ambient tempera-
ture range
Operating: 0 to +40℃, Storage: －25 to +65℃ (with no icing or condensation)
Ambient humidity
range
Operating & Storage: 35 to 85%RH (With no condensation)
Ambient
atmosphere
No corrosive gases
Vibration tolerance
Oscillation frequency: 10 to 150Hz, Half amplitude: 0.15 mm
*1
, Vibration direction:
X/Y/Z, Sweep time: 8 minute/count, Sweep count: 10
Shock resistance
Impact force: 150 m/s
2
, Test direction: 6 directions, three time each (up/down,
front/behind, left/right)
External shape
Dimension 50 mm × 41 mm × 31 mm (HxWxD)
Weight Approx. 50 g
Case material Polycarbonate
Accessories
• Special cover for FHV-LEM-S: 1
• Screws: M3×8 mm: 5 (including one spare piece)
• Instruction sheet : 1
• Compliance sheet: 1
*1. When the lens module is mounted to the product, the specificatins of vibration tolerance are changed.
3 Configuration
3 - 15
FHV Series Smart Camera Setup Manual (Z408-E1)
3-3 Lens Modules
3
3-3-1 Specifications
