• Use a DC power supply with safety measures against high-voltage spikes (safety extra low-voltage
circuits on the secondary side).
• Use an independent power source for this product. Do not use a shared power source.
• Never apply more than the rated voltage or AC power supply to this product. It may cause malfunc-
tion.
• The recommended power supplies are as follows:
- When attaching the lighting module, use S8VK-G12024 (OMRON) or S8VS-12024 (OMRON).
- When not attaching the lighting module, use S8VK-G06024 (OMRON) or S8VS-06024 (OMRON).
• Wire high-voltage cables or power cables separately from the cables of this product. If the same ca-
ble or duct is used, the product may receive induction and it may cause malfunctioning or breakage.
• Do not short-circuit load on the open collector output.
• Apply load not exceeding the rating.
• When wiring, put a crimp terminal of the specified size. Do not connect wires simply twisted together
to the power supply or terminal block directly.
• If using an I/O cable 20 m long, confirm that the power supply output is 24 VDC or higher. If it is
lower than 24 VDC, the product does not operate.
• Cut off unnecessary signal wires so that they do not contact any other signal wires.
• After wiring the cables, confirm if the power supply is appropriate, if there is miswiring such as short-
circuit of load, if the load current is appropriate, and if FG is connected appropriately. Otherwise, the
product may be broken due to miswiring etc.
• Take enough safety measures such as a failsafe circuit before using the product.
• Be sure to apply Class D grounding (100Ω or lower grounding resistance) to the case of the smart
camera and the ground wire of the I/O cable.
• Do not share the ground wire with some other devices or connect it to the beam of the building. The
product may be adversely affected.
• Determine the contact point as near as possible to shorten the ground wire as much as possible.
The product may be adversely affected.
Mounting
• When doing the following, be sure to turn OFF the power of the smart camera main unit or connect-
ed peripheral devices. Not doing so leads to a product failure.
- Cable connection and wiring
- Connector mounting/removal
- Lighting module mounting/removal
- Lens module mounting/removal
• Tighten the mounting screws securely using the defined torque and order described in the Setup
Manual.
• Mount the lens module in the correct direction. Mounting it in the wrong direction may cause mal-
function of the device or injury.
• After removing the cable, be sure to put the connector cap. If the connector cap is not put, the prod-
uct may malfunction or be broken due to entering of foreign materials.
• For the component with a lock mechanism, be sure to confirm that it is locked before using the prod-
uct.
• Do not apply torsional stress to the cable. Doing so may cause cable breakage.
• Secure the minimum bending radius of the cable. If it cannot be secured, the cable may be broken.
• Assemble as avoiding the waterproof packings and harnesses from being caught by the case, etc.
Precautions for Safe Use
16
FHV Series Smart Camera Setup Manual (Z408-E1)
