2-1
Overview of System
2-1-1
Basic System of Measurement
FHV series use pre-built packages that contain all the processing tasks (for image input, measurement
processing, displays, outputs, etc.) that are required for vision inspections.
Users arrange these packaged processes to make measurement flows with in order of execution of
the vision inspection.
An FHV executes vision inspections according to user-created flows.
Additional Information
In the FHV settings, a flow containing packaged processes that are arranged in order of execu-
tion of processing items and image processing is called a measurement flow.
Processing items and measurement flows can have more than one setting. You can switch the
setting based on the scene to inspect.
For details, refer to the Vision System FH/FHV/FZ5 series User's Manual (Cat. No. Z365).
2 Overview of FHV Series
2 - 2
FHV Series Smart Camera Setup Manual (Z408-E1)
