Chapter 8: Maintenance
Docking Funnel
WARNING: Magnetic fields can be hazardous to medical implant wearers.
Medical implant wearers should stay at least 30 cm (12 inches) away from the
underside of the platform, which is exposed during certain maintenance pro-
cedures for which the platform is tipped on its side.
8.2 Lifting the Platform Safely
If, for any reason, you need to lift the platform by hand, take care to lift from safe lifting points.
WARNING: Platform damage. Lifting the platform from the wrong points can
damage the platform.
Front Lifting Points
Lift on each side of the laser, under the upper side of the laser slot. Do not lift at the center -
there is no supporting frame. Do not lift anywhere else! Refer to the following illustration:
Figure 8-2. The upper surface of the laser slot, at both sides, not the center.
11970-000 Rev H1 LD Platform OEM User's Guide 101
