138 LD Platform OEM User's Guide 11970-000 Rev H1
10.3 Docking Station Specifications
10.3 Docking Station Specifications
Description Specification
Current 8 A
Thermal fuse in AC power switch
(10 A Time-lag fuse at switch for legacy dock)
Contacts 2
Voltage 100 to 240 VAC, 50 to 60 Hz
Power consumption 800 W
Short circuit current rating (SCCR) 1500 A
Humidity 5 to 95% non-condensing
Temperature 5 to 40°C (41 to 104°F)
Dimensions - WxDxH
with Floor plate
349 x 369 x 315 mm [13.75 x 14.5 x 12.4 inches]
495 x 495.5 x 317 mm [16 x 19.5 x 12.5 inches]
Weight 8.2 kg (18 lbs)
Mounting Wall bracket, directly to floor, or on floor with floor plate
Indicators Power on - blue
Charging - yellow
Connector For out-of-platform battery charging
