136 LD Platform OEM User's Guide 11970-000 Rev H1
10.2 Platform Specifications
Description Specification
concrete floors. F
F
is flatness, F
L
is the level. Higher F
F
numbers rep-
resent flatter floors. F
F
25 is a fairly lenient specification.
Battery
Run-time 15 hours, approx., no payload
Duty cycle 80%
Weight 19 kg (42 lb)
Voltage 22 to 30 VDC
Capacity 72 Ah
Energy 1.84 kWh nominal
Recharge time 4 hours, approx.
Life span Approximately ≥ 2000 Cycles
Sensors
Description Specification
Sensors
Safety Scanning Laser 1 at front of platform
201 mm (7.9 inches) above floor
240°, 15 m range, Class 1, eye-safe
PLd Safety per ISO-13849
Sonar Pairs
(Each pair is one emitter and one
receiver, working together)
2 at rear of platform, 2 m range
Position encoders 2 encoders (one each wheel)
2 Hall sensors (one each wheel)
Analog gyroscope (Core) 320°/s max rotation
Bumper 1 at front of platform
Side Lasers (option) 2 on sides of payload structure,
user-mounted
Low Front Laser 1 in bumper
Upward-facing camera
(Acuity option)
1 on payload structure, user-mounted
Payload Structure bumpers
(option)
6 inputs, user-designed and mounted
sensors (3 front, 3 rear)
