Flow of Test Run
Perform a test run of the inverter according to the following flow.
Item Description Reference
Installation Install the inverter according to the installation
conditions.
2-1-1 Inverter Installation on
page 2-
2
Wiring and connections Connect the inverter to the power supply and pe-
ripheral equipment.
2-3 Wiring on page 2-10
Power-on Check the points mentioned in the next page be-
fore turning the power supply ON.
3-4 Operation Items for Test Run
on page 3-18
Display status checks Check that no error is occurring on the inverter. Section 9 Troubleshooting on
page 9-1
Parameter initialization Initialize inverter parameters. 5-1 Display and Initialization on
page 5-3
Parameter setting Set the parameters required for the test run. 5-3 Motor Parameter Settings on
page 5-19
5-4 RUN command on page
5-25
No-load run Run the motor in a no-load state via Digital Opera-
tor.
3-1 Operation of Operator on
page 3-2
Load run Operate the inverter via Digital Operator with the
mechanical system connected.
3-1 Operation of Operator on
page 3-2
Operation Basic settings (operation by the basic settings re-
quired to operate and stop the inverter)
Section 5 Basic Settings on
page 5-1
Vector control (operation using vector control and
other functions)
S
ection 6 Vector Control and
Applied Functions on page
6-1
3 Operation and Test Run
3-17
M1 Series Standard Type User's Manual (I669)
3-3 Flow of Test Run
