5-5
Frequency Reference
5-5-1
Frequency Reference Selection
Select the input method for the frequency reference.
Parameter
No.
Function name Data
Default da-
ta
Unit
F01
1st Frequency Reference
Selection
0 to 15
0: Operator (
and keys) (output
frequency not inherited)
1: Analog Valtage Input (Input Termi-
nal[AI1])
2: Analog Current Input (Input T
ermi-
nal[AI2](AII))
3: Analog Valtage Input (Input Termi-
nal[AI1]) Analog Current Input (Input-
Termina (Input Terminal[AI2](AII))
5: Analog Valtage Input (Input Termi-
nal[AI2](AIV))
7: UP/DOWN control
8: Digital Operator (
and keys)
(balancelessbumpless switching availa-
ble)
10: Pattern operation
12: Pulse train input
13: Calculation result
14: RS-485 communication
15: Do not use
0
-
C30
2nd Frequency Reference
Selection
*1
2
S06 Operation command
0000 to FFFF hex
Bit1: REV
Bit0: FWD
0
Related functions Input Terminal [DI1] Function Selection to Input Terminal [DI7] Func-
tion Selection (E01 to E05, E98, E99)
Refer to 5-9-1 Input Terminal Functions on page
5-51.
*1. To enable switching to the 1st and 2nd control, allocate “12: SET (2nd control)” to either of input terminal
[DI1] to [DI7].
The frequency reference method for data selected at 1st Frequency Reference Selection (F01) and
2nd Frequency Reference Selection (C30) is as follows.
Data Frequency reference method
0
Sets the frequency reference via the Operator. When 1st control is selected, the
setting value is reflected in 1st Frequency Reference/1st Multi-step Frequency Ref-
erence 0 (C99). When 2nd control is selected, the setting value is reflected in 2nd
Frequency Reference/2nd Multi-step Frequency Reference 0 (CE109).
1 Sets the frequency reference via the analog voltage input (input terminal [AI1]).
2 Sets the frequency reference via the analog current input (input terminal [AI2](AII)).
3
Sets the value obtained by adding the analog voltage input (input terminal [AI1])
and analog current input (input terminal [AI2](AII)) as the frequency reference.
5 Basic Settings
5-27
M1 Series Standard Type User's Manual (I669)
5-5 Frequency Reference
5
5-5-1 Frequency Reference Selection
