Item No.
Pa-
rame-
ter
No.
Item Range Display item
5_54 W161
Braking Resistor
Thermal Monitor
0.0 to 100.0%
The percentage of the electronic thermal cal-
culated value for motor protection at the cur-
rent moment is displayed. If the percentage
reaches 100.0%, the dBH alarm occurs.
5_62 M59
Motor Electronic
Thermal Monitor
0.0 to 100.0%
The percentage of the electronic thermal cal-
culated value for motor protection at the cur-
rent moment is displayed. If the percentage
reaches 100.0%, the OL1 (1st motor over-
load) or OL2 (2nd motor overload) (depend-
ing on whether the 1st control or 2nd control
is selected) occurs.
5_63 W179
Total RUN Time Mon-
itor
0 to 655350 hours
The cumulative time of the inverter RUN state
is displayed.
Measurement range: 0 to 655,350 hours
Display: The cumulative operation time is dis-
played alternately in the upper digits and low-
er digits.
Example 0 <=> 535h (535 hours)
655 <=> 350h (655,350 hours)
When the lower three digits are displayed, an
h (hours) is displayed in the lowermost digit.
If 655,350 hours is reached, the display re-
mains as 655350.
7-1-4
Alarm information
Item
No.
Parameter
No.
Item Range Description
1 Latest alarm
6_00 X20
Latest Alarm Info.
Output Frequency
0.00 to 99.99,
100.0 to 590.0 [Hz]
The output frequency before slip com-
pensation is displayed in increments of
0.01 Hz. A value of 100.0 Hz or higher is
displayed in increments of 0.1 Hz.
6_01 X21
Latest Alarm Info.
Output Current
0.00 to 99.99,
100.0 to 655.3 [A]
The output current is displayed. A cur-
rent value of 100.0A or higher is dis-
played in increments of 0.1 A.
Display unit: A (Ampere)
6_02 X22
Latest Alarm Info.
Output V
oltage
0 to 999 [V]
The output voltage is displayed.
Display unit: V (Volt)
6_03 X23
Latest Alarm Info. T
or-
que Monitor
-400 to 400 [%] The torque calculated value is displayed.
6_04 X24
Latest Alarm Info.
Frequency Command
0.00 to 99.99,
100.0 to 590.0 [Hz]
The set frequency is displayed.
6_05 X25
Latest Alarm Info.
Running Status 1
F/r/----
The output operation direction is dis-
played.
7 Other Functions
7-18
M1 Series Standard Type User's Manual (I669)
