Parameter No. Function name Data
Default da-
ta
Unit
H80/A41
1st Output Current Fluctua-
tion Damping Gain/2nd
Output Current Fluctuation
Damping Gain
0.00 to 1.00 0.20 -
7-9-17
Pulse Train Frequency Input
Pulse train input can be used for the frequency reference, operation target used for frequency refer-
ence and PID feedback value in PID control.
• To use pulse train input for the frequency reference, set Frequency Reference Selection (F01/C30)
to “12: Pulse train input.”
•
To use pulse train input for the operation target, set Frequency Reference Selection (F01/C30) to
“13: Calculation result” and set Frequency Calculation Operation Target 1/2 (E131/E132) to “7:
Pulse train frequency.”
• To use pulse train input for PID feedback, set PID Control Feedback Selection (E119) to “3: Pulse
train frequency.”
• Pulse train input uses input terminals [PIA], [PIB] and [PIZ].
Parameter No. Function name Data
Default da-
ta
Unit
F01/C30
1st Frequency Reference
Selection/
2nd Frequency Reference
Selection
12: Pulse train input
13: Calculation result
0 -
E119
PID Control Feedback Se-
lection
3: Pulse train frequency 0 -
d14
Input Terminal [PIA][PIB]
Pulse Input Format Selec-
tion
0: Pulse train signing/pulse train in-
put
1: Forward/reverse rotation pulse
2: Quadrature A/B signal (B phase
lead)
3: Quadrature A/B signal (A phase
lead)
2 -
d15
Input Terminal [PIA][PIB]
Encoder Pulse Resolution
20 to 60000 1024 Pulse
d16
Input Terminal [PIA][PIB]
Pulse Scaling Factor De-
nominator
1 to 32767 1 -
d17
Input Terminal [PIA][PIB]
Pulse Scaling Factor Nu-
merator
1 to 32767 1 -
d18
Input Terminal [PIA][PIB]
Pulse T
rain Filter Time
Constant
0.000 to 5.000 0.005
s
W55
Pulse Input (A/B Phase
[PIA][PIB])
-327.68 to 327.67 - kp/s
W56 Pulse Input (Z Phase [PIZ]) 0 to 16000 - p/s
W139
Pulse Train Frequency
Monitor
-163.84 to 163.83 - %
7 Other Functions
7-145
M1 Series Standard Type User's Manual (I669)
7-9 Other Operation Functions
7
7-9-17 Pulse Train Frequency Input
