76
Section 3 SETUP
ZFV
User’s Manual
Section 3
Customizing Measurement conditions
POSITION
■ Specifying edge detection conditions
Set the direction in which edges are searched and the change in density.
● Selecting the color of edges
Select the direction of density change for the edge to be detected.
MENU Mode-[CUSTM]-[COLOR]
● Selecting the edge detection direction
Select the direction in which edges are searched.
MENU Mode-[CUSTM]-[DIRECTION]
● Changing edge detectivity
Change detectivity when a stable edge cannot be located.
MENU Mode-[CUSTM]-[EDGE SENSE]
Setting Description
WHITE (default value) A change from dark to light is judged as an edge.
BLACK A change from light to dark is judged as an edge
Setting Description
Searches from bottom to top.
Searches from top to bottom.
(default value) Searches from left to right.
Searches from right to left.
Setting Description
SENSITIVE Edge detectivity becomes sensitive.
Select this when there is little background density deviation and a stable
edge cannot be located.
NORMAL (default value) Standard detectivity.
ROUGH Edge detectivity becomes insensitive.
Select this when debris is mistakenly detected as the edge.
COLOR : BLACK
DIRECTION :
Example)
To detect this position
To Next Page
