Panasonic CF-20 series User Manual

Specifications
Thispage provides the specifications for the basic model.
The model number is different according to the unit configuration.
To check the model number:
Checkthe bottom of the computer or the box the computer came in at the time of purchase.
To check CPU speed, memory size and the flash memory drive (SSD) size:
Run the Setup Utility ( Setup Utility) and select [Information] menu.
[Processor Speed]: CPU speed, [Memory Size]: Memory size, [Hard Disk]: SSD size
Main Specifications
CPU Intel
®
Core™ i5-7Y57 vPro™ Processor (4 MB
*1
cache, 1.2 GHz up to 3.3GHz) with
Intel
®
Turbo Boost Technology
Chip Set Built-in CPU
Video controller Intel
®
HD Graphics 615 (Built-in CPU)
Main Memory
*1*2
4 GB / 8 GB / 16 GB, LPDDR3 SDRAM
Storage
*3
128 GB / 256 GB / 512 GB (SSD)
Approx. <For localized OS model> 10 GB
*3
/ <For MUI OS model> 20GB
*3
is used as a
partition with diskrecovery tools. (Users cannot use thispartition.)
Approx. 1 GB
*3
is used as a partition with system tools. (Users cannot use this partition.)
Display Method 10.1” WUXGA (1920 × 1200 dots), Aspect ratio 16:10 Anti-Reflection, Anti-Glare
Internal LCD
*4
Max. 16,777,216 colors (1920 × 1200 dots)
External Display (HDMI)
*5
Tablet : 65,536 / 16,777,216 colors (1920 x 1200 dots Max.)
Keyboard Base : 65,536 / 16,777,216 colors (1920 x 1080 dots Max.)
WirelessLAN
*6
Intel
®
Dual Band Wireless-AC 8265 ( WirelessLAN)
Bluetooth
*7
( Bluetooth)
LAN Tablet / Keyboard Base: IEEE 802.3 10Base-T / IEEE 802.3u 100BASE-TX / IEEE
802.3ab 1000BASE-T
Sound Intel
®
High Definition Audio subsystem support
SecurityChip TPM (TCG V2.0 compliant)
SD Memory Card Slot
*8
Tablet: microSD Memory Card Slot × 1 (microSDXC)
Keyboard Base: SD Memory Card Slot × 1 (SDXC UHS-Ⅰ)
Interface <Tablet>
USB Port (USB 3.0 port (Type A) × 1)
*9
/ LAN Port (RJ-45) × 1 / HDMI Port (Type A)
*10
/
3.5mm Headset jack, Stereo Headphone: 4 mW/ch(32 Ω, 1 kHz), Auto Detect of
OMTP/CTIA Monaural Microphone
<Keyboard Base>
USB Port (USB 3.0 port (Type A) × 2 / 2.0 (Type A) × 1)
*9
/ LAN Port (RJ-45) × 1 / HDMI
Port (Type A)
*10
/ VGA Port × 1 / Serial Port × 1 / Expansion Bus Connector (Dedicated
24-pin, female)

Panasonic CF-20 series Specifications

General

Operating System	Windows 10 Pro
Display	10.1" WUXGA (1920 x 1200)
RAM	16GB
Storage	Up to 512GB SSD
Durability	MIL-STD-810G
Device Type	2-in-1
Graphics	Intel HD Graphics
Wireless	Wi-Fi 802.11ac
Bluetooth	Bluetooth 4.2
Ports	USB 3.0, HDMI, Ethernet
Dimensions	275 x 211 x 24.5 mm (10.83 x 8.31 x 0.96 inches)
