Pioneer VSX 1020 User Manual

The system and the other setup11
106
En
Remote Control Mode Setup
• Default setting: 1
This sets this receiver’s remote control mode to
prevent erroneous operation when multiple
units of the receiver are being used.
1
1 Select ‘ Remote Control Mode Setup ’
from the
Other Setup menu.
2 Select the
Remote Control Mode setting
you want.
3 Select “
OK ” to change the remote control
mode.
4 Follow the instructions on the screen to
change the remote control’s setting.
See Operating multiple receivers on page 76.
5 When you’re finished, press RETURN .
You will return to the Other Setup menu.
Flicker Reduction Setup
• Default setting: OFF
The GUI screen’s resolution can be increased.
If you feel the GUI screen is hard to see, try
changing this setting. Note this setting only
affects the GUI screen; it has no influence on
the video output.
1 Select ‘ Flicker Reduction Setup ’ from the
Other Setup menu.
2 Select the Flicker Reduction setting you
want.
3 When you’re finished, press
RETURN .
You will return to the Other Setup menu.
Note
1 If you change this receiver’s setting, also change the setting on the remote control.
VSX-1020_UC.book 106 ページ ２０１０年１月７日 木曜日 午後６時０分

Pioneer VSX 1020 Specifications

General

Impedance	6 Ω
Frequency range	5 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	1 %
Audio system	Dolby TrueHD, DTS-HD Master Audio
Output power	140 W
Channels quantity	63 channels
Dimensions (WxDxH)	420 x 379 x 158 mm
Power requirements	AC 220 - 230 V, 50/60 Hz
HDMI ports quantity	7
Connectivity technology	Wired
Digital audio optical in	2
Product color	Black
Power consumption (standby)	0.6 W
Power consumption (typical)	245 W
Headphone connectivity	3.5 mm

Weight and Dimensions

Weight	10200 g
