Additional information12
116
En
Important information regarding the HDMI connection
There are cases where you may not be able to
route HDMI signals through this receiver (this
depends on the HDMI-equipped component
you are connecting–check with the
manufacturer for HDMI compatibility
information).
If you aren’t receiving HDMI signals properly
through this receiver (from your component),
please try one of the following configurations
when connecting up.
Configuration A
Use component video cables to connect the
video output of your HDMI-equipped
component to the receiver’s component video
input. The receiver can then convert the analog
component video signal to a digital HDMI
signal for transmission to the display. For this
configuration, use the most convenient
connection (digital is recommended) for
sending audio to the receiver. See the
operating instructions for more on audio
connections.
Note
• The picture quality will change slightly
during conversion.
Configuration B
Connect your HDMI-equipped component
directly to the display using an HDMI cable.
Then use the most convenient connection
(digital is recommended) for sending audio to
the receiver. See the operating instructions for
more on audio connections. Set the display
volume to minimum when using this
configuration.
Note
• If your display only has one HDMI terminal,
you can only receive HDMI video from the
connected component.
• Depending on the component, audio
output may be limited to the number of
channels available from the connected
display unit (for example audio output is
reduced to 2 channels for a monitor with
stereo audio limitations).
• If you want to switch the input function,
you’ll have to switch functions on both the
receiver and your display unit.
• Since the sound is muted on the display
when using the HDMI connection, you
must adjust the volume on the display
every time you switch input functions.
Synchronized operation not
possible using Control with
HDMI function.
• Check the HDMI connections.
• The cable may be damaged.
• Select ON for the Control with HDMI setting (see HDMI Setup on page 63).
• Turn the TV’s power on before turning on this receiver’s power.
• Set the TV side Control with HDMI setting to ON.
Symptom Remedy
VSX-1020_UC.book 116 ページ ２０１０年１月７日 木曜日 午後６時０分

Pioneer VSX 1020 Specifications

General

Impedance	6 Ω
Frequency range	5 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	1 %
Audio system	Dolby TrueHD, DTS-HD Master Audio
Output power	140 W
Channels quantity	63 channels
Dimensions (WxDxH)	420 x 379 x 158 mm
Power requirements	AC 220 - 230 V, 50/60 Hz
HDMI ports quantity	7
Connectivity technology	Wired
Digital audio optical in	2
Product color	Black
Power consumption (standby)	0.6 W
Power consumption (typical)	245 W
Headphone connectivity	3.5 mm

Weight and Dimensions

Weight	10200 g
