Pioneer VSX 1020 User Manual

Additional information12
112
En
Settings
Noisy, intermittent, or
distorted picture.
• Sometimes a video deck may output a noisy video signal (during scanning,
for example), or the video quality may just be poor (with some video game units,
for example). The picture quality may also depend on the settings, etc. of your
display device. Switch off the video converter and reconnect the source and
display device using the same type of connection (component or composite),
then start playback again.
Video signals are not output
from the component
terminal.
• When a monitor only compatible with resolutions of 480i is connected to the
component terminal and another monitor is connected to the HDMI terminal,
the video signals may not be output to the monitor connected to the component
terminal. If this happens, do the following:
– Turn off the power of the monitor connected to the HDMI terminal.
– Set RES on the VIDEO PARAMETER menu to PURE (page 70).
Symptom Remedy
The Auto MCACC Setup
continually shows an error.
• The ambient noise level may be too high. Keep the noise level in the room as
low as possible (see also Problems when using the Auto MCACC Setup on
page 40). If the noise level cannot be kept low enough, you will have to set up
the surround sound manually (page 99).
• When using only one surround back speaker, connect it to the SURROUND
BACK L (Single) terminals.
• To use a 5.1-channel speaker set, use the surround speakers for the surround
channel, not the surround back channel.
• Make sure there are no obstacles between the speakers and the microphone.
• If Reverse Phase is displayed, try the following:
– The speaker’s wiring (+ and –) may be inverted. Check the speaker
connections.
– Depending on the type of speakers and their installation conditions, Reverse
Phase may be displayed even if the speakers are properly connected. If this
happens, select GO NEXT and continue.
– If the speaker is not pointed to the microphone (listening position) or when
using speakers that affect the phase (dipole speakers, reflective speakers, etc.),
it may not be possible to properly identify the polarity.
After using the Auto MCACC
Setup, the speaker size
setting is incorrect.
• There may have been some low frequency noise in the room from an air-
conditioner, motor, etc. Switch off all other appliances in the room and use
Auto MCACC Setup again.
• Depending on a number of factors (room size, speaker placement, etc.) this
may occur in some cases. Change the speaker setting manually in Speaker
Setting on page 101, and use the ALL (Keep SP System) option for the Auto
MCACC menu in Automatic MCACC (Expert) on page 86 if this is a recurring
problem.
Can’t adjust the Fine Speaker
Distance setting (page 90)
properly.
• Check that the speakers are all in phase (make sure the positive (+) and
negative (–) terminals are matched up properly).
The display shows KEY LOCK
ON when you try to make
settings.
• With the receiver in standby, press  STANDBY/ON while holding down
SPEAKERS to disable the key lock.
Symptom Remedy
VSX-1020_UC.book 112 ページ ２０１０年１月７日 木曜日 午後６時０分

Pioneer VSX 1020 Specifications

General

Impedance	6 Ω
Frequency range	5 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	1 %
Audio system	Dolby TrueHD, DTS-HD Master Audio
Output power	140 W
Channels quantity	63 channels
Dimensions (WxDxH)	420 x 379 x 158 mm
Power requirements	AC 220 - 230 V, 50/60 Hz
HDMI ports quantity	7
Connectivity technology	Wired
Digital audio optical in	2
Product color	Black
Power consumption (standby)	0.6 W
Power consumption (typical)	245 W
Headphone connectivity	3.5 mm

Weight and Dimensions

Weight	10200 g
