Pioneer VSX 1020 User Manual

Additional information 12
127
En
English
Français
Deutsch
Nederlands
Italiano
Español
Specifications
Amplifier section
Continuous average power output of 80
watts* per channel, min., at 8 ohms, from
20 Hz to 20 000 Hz with no more than
0.08 %** total harmonic distortion.
Front (stereo) . . . . . . . . . . . . . . . .80 W + 80 W
Power output (1 kHz, 8 Ω, 0.05 %, 1 ch driven)
. . . . . . . . . . . . . . . . . . . . . . . . . 110 W per channel
Guaranteed speaker impedance
. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16 Ω to 8 Ω,
less than 8 Ω to 6 Ω (setting required)
* Measured pursuant to the Federal Trade Commission’s
Trade Regulation rule on Power Output Claims for
Amplifiers
** Measured by Audio Spectrum Analyzer
Audio Section
Input (Sensitivity/Impedance)
LINE . . . . . . . . . . . . . . . . . . . . . . 300 mV/47 kΩ
Output (Level/Impedance)
REC. . . . . . . . . . . . . . . . . . . . . . 300 mV/2.2 kΩ
Signal-to-Noise Ratio
(IHF, short circuited, A network)
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100 dB
Signal-to-Noise Ratio [EIA, at 1 W (1 kHz)]
LINE . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81 dB
Tuner Section
Frequency Range (FM) . . . 87.5 MHz to 108 MHz
Antenna Input (FM) . . . . . . . . . 75 Ω unbalanced
Frequency Range (AM) . . . . 530 kHz to 1700 kHz
Antenna (AM). . . . . . . .Loop antenna (balanced)
Video Section
Signal level
Composite . . . . . . . . . . . . . . . . . . 1 Vp-p (75 Ω)
Component Video . . . . . . . . Y: 1.0 Vp-p (75 Ω),
PB, PR: 0.7 Vp-p (75 Ω)
Corresponding maximum resolution
Component Video . . . . . . . . . . . 1080p (1125p)
(Video convert off)
Digital In/Out Section
HDMI terminal . . . . . . . . . . . . . . 19-pin (Not DVI)
HDMI output type . . . . . . . . . . . . . . . 5 V, 100 mA
USB terminal . . . . . USB2.0 Full Speed (Type A)
iPod terminal. . . . . USB, and Video (Composite)
SIRIUS antenna cable . . . . 8-pin mini DIN cable
ADAPTER PORT terminal . . . . . . . . 5 V, 100 mA
Integrated control section
Control (SR) terminal . . Ø 3.5 Mini-jack (MONO)
Control (IR) terminal. . . Ø 3.5 Mini-jack (MONO)
IR signal. . . . . . . . High Active (High Level: 2.0 V)
Miscellaneous
Power requirements. . . . . . . . . . AC 120 V, 60 Hz
Power consumption . . . . . . . . . . . . . . . . . . 245 W
In standby . . . . . . . . . . . 0.5 W (Control OFF)
0.8 W (Control ON)
Dimensions
. . . . . . 420 mm (W) x 158 mm (H) x 379 mm (D)
(16
9
/16 in. (W) x 6
1
/4 in. (H) x 14
15
/16 in. (D))
Weight (without package) . . . 10.2 kg (22 lb 8 oz)
Furnished Parts Number
MCACC Setup microphone (APM7008) . . . . . . 1
Remote control unit (AXD7595) . . . . . . . . . . . . 1
AAA/IEC R03 dry cell batteries . . . . . . . . . . . . . 2
iPod cable (ADE7129). . . . . . . . . . . . . . . . . . . . . 1
AM loop antenna . . . . . . . . . . . . . . . . . . . . . . . . 1
FM wire antenna. . . . . . . . . . . . . . . . . . . . . . . . . 1
These operating instructions
Note
• Specifications and the design are subject
to possible modifications without notice,
due to improvements.
VSX-1020_UC.book 127 ページ ２０１０年１月７日 木曜日 午後６時０分

Pioneer VSX 1020 Specifications

General

Impedance	6 Ω
Frequency range	5 - 100000 Hz
Audio output channels	7.1 channels
Audio A/D Converter (ADC)	24-bit/96kHz
Signal-to-Noise Ratio (SNR)	100 dB
Total Harmonic Distortion (THD)	1 %
Audio system	Dolby TrueHD, DTS-HD Master Audio
Output power	140 W
Channels quantity	63 channels
Dimensions (WxDxH)	420 x 379 x 158 mm
Power requirements	AC 220 - 230 V, 50/60 Hz
HDMI ports quantity	7
Connectivity technology	Wired
Digital audio optical in	2
Product color	Black
Power consumption (standby)	0.6 W
Power consumption (typical)	245 W
Headphone connectivity	3.5 mm

Weight and Dimensions

Weight	10200 g
