8.4
TRANSMISSION
4. Disconnect the transmission switch.
5. Remove the cotter pin from the shift linkage rod. Remove
the shift linkage rod and a washer from the bellcrank.
6. Loosen the jam nuts for the transmission cable. Remove the
cable from the mounting bracket.
7. Remove the mounting bolts from the transmission
mounting on both sides of the transmission.
8. Remove the four bottom transmission to frame bolts.
9. Remove the rear transmission to frame bolt.
10. Remove front transmission-to-engine mount bolt.
11. Remove transmission from right side of frame.
Transmission Switch
Jam Nuts
General Transmission Mounting
To Next Page
