8.17
TRANSMISSION
8
Exploded View, Continued
Ref. Qty. Description Ref. Qty. Description
1. 1 Plug, Fill 36. 1 Sprocket, 22T
2. 1 Plug, Drain, Magnetic 37. 1 Lockout Disc
3. 5 Screw, Self-Tapping 1/4-20 38. 1 Detent Pawl
4. 2 Screw, 5/16-18 39. 1 Detent Star
5. 4 Screw, 1/4-20 40. 1 Bellcrank, Shift Drum
6. 15 Screws, Self-Tapping 5/16-18 41. 1 Output Shaft, Front Main
7. 1 Nut, Nylon Lock 42. 1 Thrust Button
8. 2 Nut, Nylon Lock 43. 1 Rail, Shift Shaft
9. 1 Washer 44. 1 Shift Shaft
10. 1 Washer 45. 1 Output Shaft, Rear Main
11. 1 Washer 46. 1 Gear, 33T
12. 4 Dowel Pin 47. 1 Sprocket, 19T
13. 1 Retaining Ring, External 48. 4 Engagement Dog, 6 Face
14. 1 Retaining Ring, External 49. 1 Reverse Shaft
15. 2 Retaining Ring, External 50. 1 Gear, 33T
16. 1 Spacer 51. 1 Gear, Mid-Output, 47T
17. 1 Thrust Washer 52. 1 Gear, Mid-Output, 60T
18. 1 Shim 53. 1 Vent Tube
19. 1 Shim 54. 1 Sprocket, 38T
20. 1 Needle Bearing 55. 1 Gear Set, 10T/31T
21. 4 Ball Bearing 56. 2 Shift Fork w/Pin
22. 4 Ball Bearing 57. 1 Input Shaft, 37/19/15
23. 1 Needle Bearing 58. 1 Cover, Center Drive Bearing
24. 1 Plain Bearing 59. - N/A
25. 1 Needle Bearing 60. 1 Silent Chain, 11W/40P
26. 1 Ball Bearing 61. 1 Chain
27. 1 Spring, Compression 62. 1 Switch, 6-Pin Rotary
28. 2 Spring, Wave 63. 1 Seal, Dual Lip
29. 1 Cover, Sector Gear 64. 2 Seal, Triple Lip
30. 1 Cover, LH Input 65. 1 O-Ring
31. 1 Gearcase, Main 66. 1 O-Ring
32. 1 Shift Drum 67. 1 O-Ring
33. 1 Cover, Output 68. - N/A
34. 1 Sector Gear, 16T 69. 1 Bracket, Torque Stop
35. 1 Sector Gear, 31T 70. 1 Bracket, Transmission Mount
To Next Page
