1.11
9924882 - 2013–2014 RZR 800
© Copyright 2013 Polaris Sales Inc.
Drivetrain
Fluid Type / Capacity 22 oz. (650 ml)
Clutch Type
Standard PVT
Drive Belt 3211133
Steering / Suspension
Front Suspension / Shock
Independent Dual A-arm
Standard: Monotube
FOX™: PODIUM
Front Travel 12 in. / 30.5 cm
Rear Suspension / Shock
Rolled IRS w/Anti-Sway
Bar Standard: Monotube
FOX™: PODIUM
Rear Travel 12 in. / 30.5 cm
Shock Preload
Adjustment
Front / Rear
Standard: Cam
Adjustment
FOX™: Threaded
Spanner Wrench
Adjustment
Toe Out
1/8 - 1/4 in. (3 - 6.4 mm)
Wheels / Brakes
Front Wheel Type / Size
Aluminum / 12 x 6
Rear Wheel Type / Size
Aluminum / 12 x 8
Front Tire Type / Size
ITP “900XCT” / 27 x 9
R12
Maxxis Bighorn / 26 x 9
R12
Rear Tire Type / Size
ITP “900XCT” / 27 x 11
R12
Maxxis Bighorn / 26 x 12
R12
Tire Air Pressure - Front /
Rear
8 psi (55 kPa)
Brake - Front / Rear
Foot Actuated - 4 Wheel
Hydraulic Disc
Brake Fluid DOT 4
CLUTCH CHART
Altitude
Shift
Weight
Drive
Spring
Driven
Spring
Me-
ters
(Fee-
t)
0-1500
(0-5000)
23-62
(56323-
37)
Green
(70437-
89)
Blk /
Almond
(704316-
7)
1500-3700
(5000 -
12000)
23-58
(B)
(13229-
11)
Green
(70437-
89)
Blk /
Almond
(704316-
7)
GENERAL INFORMATION
1
