Raymarine a67 Wi-Fi User Manual

Course-Up
N
N
1 2
D12 21 0-1
ItemDescription
1
Currentcourseupwards.
2Asyourvessel'sheadingchanges:
•Radarpictureisxed
•SHMrotatesaccordingly
Ifyouselectanewcourse,thepicturewillresettodisplaythe
newcourseupwards.
ThereferenceusedforCourse-Updependsupontheinformation
availableatagiventime.Thesystemalwaysprioritizesthis
informationinthefollowingorder:
1.Bearingfromorigintodestination,thatis,intendedcourse.
2.LockedheadingfromanAutopilot.
3.Bearingtowaypoint.
4.Instantaneousheading(whencourse-upisselected).
Note:Ifheadingdatabecomesunavailablewhilstinthis
mode,awarningmessagewillbeshown,thestatusbar
indicatestheCourseUpinbracketsandtheradaruses0°
headinginrelativemotion.Whenheadingdatabecomes
availableoncemore,Course-Upmodeisreinstated.
Selectingtheradarorientationmode
Fromtheradarapplication:
1.SelectMenu.
2.SelectPresentation.
3.SelectOrientation&MotionMode.
4.SelectOrientation.
5.Selecttherequiredorientation.
Radarmotionmodesoverview
Themotionmodecontrolstherelationshipbetweentheradar
andyourvessel.Therearetwomodes:
•Relativemotion.
•Truemotion.
Theselectedmotionmodeisdisplayedinthestatusbar.The
defaultsettingisRelativeMotionwithzerooffset.
RelativeMotion(RM)withoptionalVesselOffset
WhenthemotionmodeissettoRelative,thepositionofyour
vesselisxedonthescreenandallthetargetsmoverelative
tothevessel.Youcanspecifywhetherthevesselisxedinthe
centerofthewindow(0offset)oroffsetby1/3or2/3toincrease
theviewahead,asshownbelow:
Examples:
D12211-1
D12212-1
D12213-1
0offset1/3offset2/3offset
Thedefaultmotionmodeis“Relative”,withzerooffset.
TrueMotion(TM)
WhenthemotionmodeissettoTrue,xedradartargets
maintainaconstantpositionandmovingvessels(includingyour
vessel)travelintrueperspectivetoeachotherandtoxed
landmassesonthescreen.Asthevessel’spositionapproaches
theedgeofthescreen,theradarpictureisautomaticallyresetto
revealtheareaahead.
Note:Ifheadingandpositiondatabecomeunavailablewhen
Truemotionisselected,awarningmessagewillbeshown,
themodewillreverttorelativemotionandbenotedinthe
statusbarinbrackets,forexample,(TM).
Note:ItisnotpossibletoselectTrueMotionwhenthe
orientationissettoHeadUp.
Selectingtheradarmotionmode
Fromtheradarapplication:
1.SelectMenu.
2.SelectPresentation.
3.SelectOrientation&MotionMode.
4.SelectMotionMode.
SelectingMotionModewillswitchbetweenTrueandRelative.
Changingtheradarvesseloffset
RadaroffsetisonlyavailableinRelativemotionmode.
Fromtheradarapplication:
1.SelectMenu.
2.SelectPresentation.
3.SelectOrientation&MotionMode.
4.SelectVesselOffset.
5.Selecttherequiredoffsetvalue.
Radarapplication
167
