Raymarine a67 Wi-Fi User Manual

5.1Selectingalocation
Warning:Potentialignitionsource
ThisproductisNOTapprovedforusein
hazardous/ammableatmospheres.DoNOTinstall
inahazardous/ammableatmosphere(suchasin
anengineroomornearfueltanks).
Generallocationrequirements
Whenselectingalocationforyourdisplayitisimportantto
consideranumberoffactors.
Keyfactorswhichcanaffectproductperformanceare:
•Ventilation
Toensureadequateairow:
–Ensurethatequipmentismountedinacompartmentof
suitablesize.
–Ensurethatventilationholesarenotobstructed.Allow
adequateseparationofequipment.
Anyspecicrequirementsforeachsystemcomponentare
providedlaterinthischapter.
•Mountingsurface
Ensureequipmentisadequatelysupportedonasecure
surface.Donotmountunitsorcutholesinplaceswhichmay
damagethestructureofthevessel.
•Cableentry
Ensuretheunitismountedinalocationwhichallowsproper
routingandconnectionofcables:
–Minimumbendradiusof100mm(3.94in)unlessotherwise
stated.
–Usecablesupportstopreventstressonconnectors.
•Wateringress
Thedisplayissuitableformountingbothaboveandbelow
decks.ItiswaterprooftoIPX6standard.Althoughtheunitis
waterproof,itisgoodpracticetolocateitinaprotectedarea
awayfromprolongedanddirectexposuretorainandsalt
spray.
•Electricalinterference
Selectalocationthatisfarenoughawayfromdevicesthat
maycauseinterference,suchasmotors,generatorsandradio
transmitters/receivers.
•Powersupply
Selectalocationthatisascloseaspossibletothevessel’sDC
powersource.Thiswillhelptokeepcablerunstoaminimum.
Compasssafedistance
Topreventpotentialinterferencewiththevessel'smagnetic
compasses,ensureanadequatedistanceismaintainedfrom
thedisplay.
Whenchoosingasuitablelocationforthemultifunctiondisplay
youshouldaimtomaintainthemaximumpossibledistance
betweenthedisplayandanycompasses.Typicallythisdistance
shouldbeatleast1m(3ft)inalldirections.Howeverforsome
smallervesselsitmaynotbepossibletolocatethedisplaythis
farawayfromacompass.Inthissituation,thefollowinggures
providetheminimumsafedistancethatshouldbemaintained
betweenthedisplayandanycompasses.
D12 20 3-1
200 mm
(7.87 in)
350 mm
(13.8 in)
300 mm
(11.8 in
)
700 mm
(27.5 in)
500 mm
(19.7 in)
250 mm
(9.84 in)
1
2
3
4
5
6
Item
Compasspositionin
relationtodisplay
Minimumsafe
distancefromdisplay
1Top
200mm(7.87in.)
2Rear
500mm(19.7in.)
3Right-handside
350mm(13.8in.)
4Underside
300mm(11.8in.)
5
Front
700mm(27.5in.)
6
Left-handside250mm(9.84in.)
GPSlocationrequirements
Inadditiontogeneralguidelinesconcerningthelocationof
marineelectronics,thereareanumberofenvironmentalfactors
toconsiderwheninstallingequipmentwithaninternalGPS
antenna.
Mountinglocation
•AboveDecksmounting:
ProvidesoptimalGPSperformance.(Forequipmentwith
appropriatewaterproofrating.)
•BelowDecksmounting:
GPSperformancemaybelesseffectiveandmayrequirean
externalGPSantennamountedabovedecks.
D115 37-2
1
2
3
1
2
3
1.
ThislocationprovidesoptimalGPSperformance(above
decks).
2.
Inthislocation,GPSperformancemaybelesseffective.
3.
ThislocationisNOTrecommendedforGPSantenna.
64NewaSeries/NewcSeries/NeweSeries
