Fusionlinkconnection
YoucanconnectaFusion700seriesmarineentertainment
systemtoyourmultifunctiondisplay.
Directconnection
1
2
3 4
D12741-1
1.Multifunctiondisplay.
2.Fusionsystem.
3.RayNettoSeaT alk
hs
cable.
4.Fusionethernetconnector.
Directconnectionwithnetworkedmultifunctiondisplays
3 2
D12742-1
4
1
5
1.Fusionsystem.
2.Fusionethernetconnector.
3.RayNettoSeaT alk
hs
cable.
4.Directlyconnectedmultifunctiondisplay.
5.Networkedmultifunctiondisplays.
Note:TheFusionentertainmentsystemcanbecontrolledby
adirectlyconnectedmultifunctiondisplayorbyanetworked
multifunctiondisplay.
Networkconnection
D12740-1
6
5
1
2
6
3 4
1.Networkswitch.
2.Fusionsystem.
3.RayNettoSeaT alk
hs
cable.
4.Fusionethernetconnector.
5.SecondFusionsystem(themultifunctiondisplaycanbe
connectedtomultipleFusionentertainmentsystems).
6.Networkedmultifunctiondisplays.
Note:TheFusionentertainmentsystemcanbecontrolled
byanycompatiblenetworkedmultifunctiondisplaywhen
connectedusinganetworkswitch.
