SeaTalk
ng
cablingcomponents
SeaTalk
ng
cablingcomponentsandtheirpurposes.
Connection/CableNotes
Backbonecable(variouslengths)Themaincablecarryingdata.Spurs
fromthebackboneareusedto
connectSeaTalk
ng
devices.
T-piececonnectorUsedtomakejunctionsinthe
backbonetowhichdevicescanthen
beconnected.
Terminator
Requiredateitherendofthe
backbone.
InlineterminatorUsedtoconnectaspurcable
directlytotheendofabackbone;
usefulforlongercableruns.
Spurcable
Usedtoconnectdevicestothe
backbone.Devicesmaybedaisy
chainedorconnecteddirectlytothe
T-pieces.
SeaTalk
ng
5–wayconnector
Usedtobranch,split,ormake
additionalconnectionsinSeaTalkor
SeaTalk
ng
networks.
BlankingplugInsertedintounusedspurconnector
positionsina5-wayconnectoror
T-piece.
SeaTalk
ng
cablesandaccessories
SeaTalk
ng
cablesandaccessoriesforusewithcompatible
products.
DescriptionPartNoNotes
SeaTalk
ng
starterkit
T70134Includes:
•1x5Wayconnector(A06064)
•2xBackboneterminator
(A06031)
•1x3m(9.8ft)spurcable
(A06040)
•1xPowercable(A06049)
SeaTalk
ng
BackboneKit
A25062Includes:
•2x5m(16.4ft)Backbone
cable(A06036)
•1x20m(65.6ft)Backbone
cable(A06037)
•4xT-piece(A06028)
•2xBackboneterminator
(A06031)
•1xPowercable(A06049)
SeaTalk
ng
0.4m(1.3ft)
spur
A06038
SeaTalk
ng
1m(3.3ft)
spur
A06039
SeaTalk
ng
3m(9.8ft)
spur
A06040
SeaTalk
ng
5m(16.4ft)
spur
A06041
SeaTalk
ng
0.4m(1.3ft)
elbowspur
A06042
SeaTalk
ng
0.4m(1.3ft)
backbone
A06033
SeaTalk
ng
1m(3.3ft)
backbone
A06034
DescriptionPartNoNotes
SeaTalk
ng
3m(9.8ft)
backbone
A06035
SeaTalk
ng
5m(16.4ft)
backbone
A06036
SeaTalk
ng
9m(29.5ft)
backbone
A06068
SeaTalk
ng
20m(65.6ft)
backbone
A06037
SeaTalk
ng
tobareends
1m(3.3ft)spur
A06043
SeaTalk
ng
tobareends
3m(9.8ft)spur
A06044
SeaTalk
ng
Powercable
A06049
SeaTalk
ng
Terminator
A06031
SeaTalk
ng
T-piece
A06028Provides1xspurconnection
SeaTalk
ng
5–way
connector
A06064Provides3xspurconnections
SeaTalk
ng
backbone
extender
A06030
SeaTalktoSeaTalk
ng
converter
E22158
AllowstheconnectionofSeaTalk
devicestoaSeaTalk
ng
system.
SeaTalk
ng
Inline
terminator
A80001
Providesdirectconnectionof
aspurcabletotheendofa
backbonecable.NoT-piece
required.
SeaTalk
ng
Blankingplug
A06032
SeaTalk(3pin)to
SeaTalk
ng
adaptorcable
0.4m(1.3ft)
A06047
SeaTalk2(5pin)to
SeaTalk
ng
adaptorcable
0.4m(1.3ft)
A06048
DeviceNetadaptor
cable(Female)
A06045
AllowstheconnectionofNMEA
2000devicestoaSeaTalk
ng
system.
DeviceNetadaptor
cable(Male)
A06046
AllowstheconnectionofNMEA
2000devicestoaSeaTalk
ng
system.
DeviceNetadaptor
cable(Female)tobare
ends.
E05026
AllowstheconnectionofNMEA
2000devicestoaSeaTalk
ng
system.
DeviceNetadaptor
cable(Male)tobare
ends.
E52027
AllowstheconnectionofNMEA
2000devicestoaSeaTalk
ng
system.
52NewaSeries/NewcSeries/NeweSeries
