49
Chapter6:Sonarapp
6.
1Sonarappoverview
TheSonarappdisplaysavisualizationoftheechoesreceivedfrom
aSonarmoduleandtransducer.TheSonarappiscompatiblewith
Traditional,CHIRP,DownVision™,SideVision™andRealVision™3D
sonarmodulesandtransducers.TheSonarappbuildsanunderwater
viewofbottomstructureandtargetsinthewatercolumn.
MultipleSonarmodulescanbeconnectedatthesametime.Sonar
modulescanbeinternal(built-intoyourMFD)orexternal(aseparate
boxonyournetwork).
ForeachinstanceoftheSonarappyoucanselectwhichSonar
moduleandchannelthatyouwanttouse,theSonarmoduleand
channelselectionwillpersistoverapowercycle.
TheSonarappcanbedisplayedinbothFullscreenandsplitscreenapp
pages.Apppagesmayconsistofupto4instancesoftheSonarapp.
Sonarappcontrols
IconDescriptionAction
HomeiconTakesyoutotheHomescreen
Waypoint/
MOB
Placewaypoint/activateManoverboard
(MOB)alarm
