54
Checkyourtransducerconnection(s)arecorrectandfreefrom
damage
,thenpowercycleyoursystem.Ifthetransducerisstillnot
foundthenrefertoyourequipment’sinstallationdocumentationfor
furthertroubleshootinginformation.
SelectingaSonarchannel
ThefirsttimeyouopenanewSonarapppageyouwillberequested
toselectachannel,subsequentlyyoucanchangethesonarchannel
byselectingachanneliconfromtheSonarappmenu.
1.SelectarelevantchanneliconfromtheMenu.
2.Alternativelyselect
AllchannelsfromtheMenuandthenchoose
yourdesiredsonarmoduleandchannel.
Sonarchannels
TheSonarchannelsthatareavailabledependontheSonarmodule
andtransduceryouhaveconnected.
R ealVision™3D SideVision™ DownVision™
HighCHIRP/High
Frequency
MediumCHIRP/
MediumFrequency
LowCHIRP/Low
Frequency
