2.3Compatibletransducers—Axiom™ProMFDs
DependingonyourMFDvariantyoucanconnectthefollowingtransducertypesdirectlytoyourMFD:
AxiomProS:
•CPT-SCHIRPconicalbeamtransducersthatutilizethe9pinDown
Vision™connector.
AxiomProRVX—RVconnection:
•RealVision™3Dtransducers.
•DownVision™transducers.
•Non-CHIRPtransducerscanbeconnectedusingavailableadaptorcables.RefertotheRaymarine®
websiteforcompatibletransducers:www.raymarine.com/transducers.
AxiomProRVX—Xconnection:
•1kWtransducers.RefertotheRaymarine®websiteforcompatibletransducers:
www.raymarine.com/transducers.
•Othertransducersusingavailableadaptorcables.
RealVisiontransducers
ThetransducerslistedbelowcanbeconnecteddirectlytoRealVision™3DvariantMFDs.
Product
numberT ransducerMountingDescription
A 80464
Transom
RV-100RealVision™3D
PlasticTransducer
A 80465
Thru-Hull
RV-200RealVision™
3DBronze0°Single
Transducer
A 80466
Thru-Hull
RV-212PRealVision™3D
Bronze12°Split-pairPort
Transducer
A 80467
Thru-Hull
RV-212SRealVision™
3DBronze12°Split-pair
StarboardTransducer
A 80468
Thru-Hull
RV-220PRealVision™3D
Bronze20°Split-pairPort
Transducer
A 80469
Thru-Hull
RV-220SRealVision™
3DBronze20°Split-pair
StarboardTransducer
