4.3NMEA2000(Sea
Talkng®)connection
TheMFDcantransmitandreceivedatafromdevicesconnectedonacompliantCANbusnetwork.
TheMFDisconnectedtothebackboneusingtheMFD’sNMEA2000connector.
1.UsethesuppliedDeviceNettoSea Talkng®adaptorcabletoconnectyourMFDtoaSeaTalkng®
backbone.
2.AlternativelyyourcanconnectyourMFDtoaNMEA2000backboneusingastandardDeviceNet
cable(notsupplied).
Note:
1.Sea Talkng®andNMEA2000devicesmustbeconnectedtoacorrectlyterminatedbackbone
thattheMFDisalsoconnectedto.DevicescannotbeconnecteddirectlytotheMFD.
2.RefertotheinstructionssuppliedwithyourSea Talkng®/NMEA2000devicefordetailson
creatingabackbone.
