Raymarine Dragonfly User Manual

3.2Partssupplied
Thepartssuppliedwithyourproductareshownbelow.
Suppliedwith:E70085,E70226,E70230andE70231
ItemDescriptionQty
00
0
Display1
Displaycradle.1
00
Displaycradlebase1
Cradlesecuringbolt
1
Cradlemountingxings
3
Documentationpack1
Suppliedwith:E70085andE70231
ItemDescriptionQty
00
CPT-60DownVision
TM
transommount
transducer(includingtted6m(19.7
ft.)transducercableand2m(6.6ft.)
powercable–notshown.)
1
Escutcheon(forthroughtransomcable
installation.)
1
Escutcheonmountingscrews2
Transducerbracketmountingscrews3
P-clipsandscrews3
3.3Compatibletransducers
ThisproductiscompatiblewiththefollowingRaymarine
DownVision
TM
transducers.
Part
numberDescription
Mounting
Type
Construc-
tion
A80195
CPT-60
Dragony
TM
transducer
TransomPlastic
A80278
CPT-70
Dragony
TM
transducer
Through-
hull
Plastic
A80279
CPT-80
Dragony
TM
transducer
Through-
hull
Bronze
Planningtheinstallation
17
