3.7Selectingalocationforthe
transducer
Thisproductissuppliedwithatransommounttransducer.The
guidelinesbelowshouldbefollowedwhenselectingalocation
forthetransducer.
Note:Thetransducerisnotsuitableformountingonvessels
wherethetransomisaftofthepropeller(s).
Forbestperformancethetransducermustbeinstalledina
locationwiththeleastturbulenceandaeration.Themost
effectivewaytodeterminethisisbycheckingthewaterow
aroundthetransomwhilstunderway.
•Thetransducershouldbemountedclosetothekeel
(centreline)ofthevessel,sothatthetransducerremainsfully
submergedwhenthevesselisturning.
•Thetransducermustbemountedasuitabledistancefrom
thepropeller(s)toavoidwake.
•Forclockwiserotatingpropellersthetransducershouldbe
mountedonthestarboardside,foranti-clockwiserotating
propellersthetransducershouldbemountedontheportside.
D12 64 0-1
•Onatwinenginevesselthetransducershouldbemounted
betweentheengines.
D12 64 1-1
•Turbulencecanalsobecausedbyanumberofotherfactors
suchassteps,ribs,strakes,androwsofrivets.Theturbulence
appearsaftoftheselocations.
Planningtheinstallation
19
