informationandyouareadvisedthaterrorsinsuchinformation
maycausetheproducttomalfunction.Raymarineisnot
responsiblefordamagesorinjuriescausedbyyouruseor
inabilitytousetheproduct,bytheinteractionoftheproductwith
productsmanufacturedbyothers,orbyerrorsinchartdataor
informationutilizedbytheproductandsuppliedbythirdparties.
Chartcardsandmemorycards
Memorycardsareusedforarchivingdataandchartcards
provideadditionalorupgradedcharts.
Compatiblecards
Thefollowingtypesofmemoryorchartcardarecompatiblewith
yourRaymarineproduct:
•microSecureDigitalStandard-Capacity(microSDSC)
•microSecureDigitalHigh-Capacity(microSDHC)
Note:Themaximumcardcapacitysupportedis32GB.
Speedclassrating
ForbestperformanceitisrecommendedthatyouuseClass10
orUHS(UltraHighSpeed)classmemorycards.
Chartcards
Yourproductispre-loadedwithelectroniccharts(worldwide
basemap).Ifyouwishtousedifferentchartdata,youcaninsert
compatiblechartcardsintotheunit'scardslot.
Usebrandedchartcardsandmemorycards
Whenarchivingdata,Raymarinerecommendstheuseofquality
brandedmemorycards.Somebrandsofmemorycardmaynot
workinyourunit.Pleasecontactcustomersupportforalist
ofrecommendedcards.
EMCinstallationguidelines
Raymarineequipmentandaccessoriesconformtothe
appropriateElectromagneticCompatibility(EMC)regulations,
tominimizeelectromagneticinterferencebetweenequipment
andminimizetheeffectsuchinterferencecouldhaveonthe
performanceofyoursystem
CorrectinstallationisrequiredtoensurethatEMCperformance
isnotcompromised.
Note:InareasofextremeEMCinterference,someslight
interferencemaybenoticedontheproduct.Wherethisoccurs
theproductandthesourceoftheinterferenceshouldbe
separatedbyagreaterdistance.
ForoptimumEMCperformancewerecommendthatwherever
possible:
•Raymarineequipmentandcablesconnectedtoitare:
–Atleast1m(3ft)fromanyequipmenttransmittingor
cablescarryingradiosignalse.g.VHFradios,cablesand
antennas.InthecaseofSSBradios,thedistanceshould
beincreasedto7ft(2m).
–Morethan2m(7ft)fromthepathofaradarbeam.A
radarbeamcannormallybeassumedtospread20degrees
aboveandbelowtheradiatingelement.
•Theproductissuppliedfromaseparatebatteryfromthatused
forenginestart.Thisisimportanttopreventerraticbehavior
anddatalosswhichcanoccuriftheenginestartdoesnot
haveaseparatebattery.
•Raymarinespeciedcablesareused.
•Cablesarenotcutorextended,unlessdoingsoisdetailedin
theinstallationmanual.
Note:Whereconstraintsontheinstallationprevent
anyoftheaboverecommendations,alwaysensurethe
maximumpossibleseparationbetweendifferentitemsof
electricalequipment,toprovidethebestconditionsforEMC
performancethroughouttheinstallation
Thirdpartysoftwarelicense
agreements
Thisproductissubjecttocertainthirdpartysoftwarelicense
agreementsaslistedbelow:
•GNU—LGPL/GPL
•JPEGlibraries
•OpenSSL
•FreeType
Thelicenseagreementsfortheabovecanbefoundon
thewebsitewww.raymarine.comandontheaccompanying
documentationCDifsupplied.
Declarationofconformity
RaymarineUKLtd.declaresthatthisproductiscompliantwith
theessentialrequirementsofEMCdirective2004/108/EC.
TheoriginalDeclarationofConformitycerticatemaybeviewed
ontherelevantproductpageatwww.raymarine.com.
Pixeldefectpolicy
IncommonwithallTFTunits,thescreenmayexhibitafew
wrongly-illuminated(“dead”)pixels.Thesemayappearasblack
pixelsinalightareaofthescreenorascoloredpixelsinblack
areas.
IfyourdisplayexhibitsMOREthanthenumberof
wrongly-illuminatedpixelsallowed(refertotheproducttechnical
specicationfordetails),pleasecontactyourlocalRaymarine
servicecenterforfurtheradvice.
Warrantypolicy
Yourproductiswarrantedtobefreefromdefectsinmaterials
andworkmanshipforaperiodof1yearfromthedateofrst
purchaseoftheproductor,ifinstalledonanewboat,thedateof
rstboatdeliverytotheOriginalCustomer(pleaseretainproof
ofpurchaseincaseyouneedtoclaim).
ThefulldetailsoftheLimitedWarrantyPolicy
andregistrationprocessareavailableonlineat:
www.raymarine.com/warranty-dragony.
IfyoudonothaveaccesstotheInternet,pleasephonethe
relevantnumberbelowtoobtainwarrantypolicyinformation:
IntheUSA:
•Tel:+16033247900
•TollFree:+18005395539
IntheUK,Europe,theMiddleEast,orFarEast:
•Tel:+44(0)1329246777
Warrantyregistration
ToregisteryourRaymarineproductownership,pleasevisit
www.raymarine.comandregisteronline.
Itisimportantthatyouregisteryourproducttoreceivefull
warrantybenets.Yourunitpackageincludesabarcodelabel
indicatingtheserialnumberoftheunit.Youwillneedthisserial
numberwhenregisteringyourproductonline.Y oushouldretain
thelabelforfuturereference.
8
Dragony/Dragony7
