7inchproductdimensions
D13037-1
191 mm (7.52 in)
61 mm (2.4 in)
84 mm (3.3 in)
156 mm (6.1 in)
208 mm (8.2 in)
90 mm (3.5 in)17 mm (0.7 in)
0
0
0
0
00
7inchdisplaycradleorientation
The7inchdisplaycanbemountedin‘cradleup’or‘cradle
down’orientation.
CradleUpCradleDown
Thecradlemountingstepsarethesameregardlessof
orientation.
3.10Installationprocess
Thestepslistedbelowarerequiredtosuccessfullyinstallyour
productandensureoptimumperformance.
1.Mountingthetransducer.
2.Mountingthedisplay.
3.Testingthetransducer.
4.Finishingthetransducermounting.
22
Dragony/Dragony7
