ConfiguringT
ransducersettings
ForsystemssetupwithSonar,youshouldconfigureyourtransducer
settings.
1.Select TransducerfromtheSonarapp’s Settingsmenu: Menu
>Settings>T ransducer
2.Selecthowyouwantyourdepthtoappear:
i.Belowtransducer(default)—Nooffsetrequired
ii.Belowkeel—Enterthedistancebetweenthetransducerface
andthebottomoftheKeel.
iii.Belowwaterline—Enterthedistancebetweenthebottomof
yourKeelandthewaterline.
3.Ifyourtransducerincludesatemperaturesensorthenyoucanalso
configuretemperaturesettingsasfollows:
i.Enableordisabletemperaturereadingsasrequired.
ii.Ifenabled,checkthetemperaturereadingagainsttheactual
watertemperature.
iii.Ifthecurrentreadingrequiresadjustment,select
Calibrate
tempandenterthedifferencebetweenyour2readings.
AssigningafunctiontotheUserProgrammable
Button
Y
oucanassignafunctiontotheUserProgrammableButtononan
Axiom™ProMFD.
1.Pressandholdthe UserProgrammableButton.
2.Selectthefunctionfromthelist.
