3.2Controls—AxiomProvariants
Inadditiontoitstouchscreen,theAxiomProalsoincludesphysicalbuttonsthatcanbeusedto
controltheMFD
.
1. Touchscreen—ThetouchscreencanbeusedtocontroltheMFD.
2.
Home—PresstodisplaytheHomescreen.
3.Menu—Presstoopenorclosemenus.
4.
Uni-controller—TheUni-controllerconsistsofacenter OKbutton, Directionalcontrolsand
a
Rotaryknob.
5.
UserProgrammableButton—Youcanselectafunctionforthisbutton.
6.Waypoint/MOB—Pressmomentarilytoplaceawaypointatyourvessel’slocation.Alongpress
activatestheManoverboardalarm.
7.Power—PresstopowerontheMFD.WhenpoweredonpresstoopentheShortcutspage.
8.
MicroSDcardreader—2xMicroSDcardslots.
9.Pilot—PressmomentarilytodisplayorhidethePilotsidebar.Alongpressengagestheautopilot
inlockedheadingmode,ordisengagesanactiveautopilot.
10. Switchpane—Pressmomentarilytoswitchtheactivepaneinasplitscreenpage.Alongpress
expandstheselectedpane.
11.
Back—Presstoreturntothepreviousmenuordialog.
Poweringonthedisplay
1.Pressthepowerbuttontopoweronthedisplay.
Poweringoffthedisplay
1.Pressandholdthe
Powerbuttonforapproximately6seconds.
Note:Whenpoweredoff ,theunitmaystilldrawasmallamountofpowerfromthebattery,ifthisis
aconcernunplugthepowersupplyorswitchoffatthebreaker.
