4.
1
Accepting
the
Limitations
on
Use
After
your
MFD
has
powered
up
the
Homescreen
is
displayed.
1.
Before
using
the
MFD
you
must
accept
the
Limitations
on
Use
(L
oU)
disclaimer
.
T
o
view
the
full
LoU
Disclaimer
,
select
‘more
details’
.
The
L
oU
acknowledgment
is
displayed
each
time
the
display
is
powered
on
and
for
each
new
user
profile.
The
full
L
oU
te
xt
can
be
accessed
at
any
time
from
the
Getting
started
tab:
Homescreen
>
Settings
>
Getting
started
>
View
terms
of
use
.
30
195
197
