Chapter4:A
utopilotcontrol
4.1Autopilotcontrol
Y ourMFDcanbeintegratedwithanEvolutionautopilotsystemand
actastheautopilot’scontroller.Pleaserefertothedocumentation
suppliedwithyourautopilotfordetailsoninstallingandconnecting
yourautopilottoyourMFD.
AutopilotcontrolfromyourMFDcanbeenabledanddisabledfrom
the
A
utopilottabinthe
Settingsmenu: Homescreen>Settings>
A
utopilot>Pilotcontrol.
1. Piloticon—With Autopilotcontrolenabled,thePiloticonis
displayedonscreen;selectingtheicondisplaysthePilotsidebar.
WhentheAutopilotisengagedthePiloticonisreplacedwiththe
Disengagepiloticon.
2.Pilotsidebar—ThePilotsidebarprovidescontrolsandinformation
relatingtoyourautopilotsystem.WiththeAutopilotengagedthe
Pilotsidebar’scontentisexpandedtoprovidefurthercontrols
andinformation.ThePilotsidebarcanbehiddenbyswipingthe
sidebartotheleft.Thesidebarcanbedisplayedagainbyswiping
fromtheleftofthescreentowardsthecenterofthescreen.
Engagingtheautopilot—Lockedheading
WithAutopilotcontrolenabled:
1.ForWheelandTillerpilots,engagethemechanicaldrivebyeither
engagingthewheeldrive’sclutchorattachingthepushrodonto
thetillerpin.
2.Selectthe Autopiloticon.
ThePilotsidebarisdisplayed.
3.Select
SteertoHdg.
