Vision™transducers
ThetransducerslistedbelowcanbeconnecteddirectlytoDownVision™(DV)variantMFDs.An
adaptorisrequiredforconnectiontoRealVision™(RV)variantMFDs.
ProductnumberT
ransducerMountingDescription
A
80351
T
ransom
CPT-100DVSplastic
(replacementfor
A80270CPT-100)
A 80277
Thru-hull
CPT-110plastic
A 80271
Thru-hull
CPT-120bronze
CHIRPconicalbeamtransducers(usingDown Vision™typeconnector)
ThetransducerslistedbelowcanbeconnecteddirectlytoDownVision™(DV)variantMFDsorviaan
adaptorcabletoRealVision™(RV),RealVision™+1kW(RVX)andSonar(S)variantMFDs.
CPT-StransducersuseCHIRPsonartechnologytoproduceaconical-shapedsonarbeam.
Note:CPT-StransducersdoNO TofferDownVision™capabilities.
ProductnumberT ransducerMountingDescription
E70342
Transom
CPT-Splastic
E70339
Thru-hull
CPT-S0°angled
elementplastic
A 80448
Thru-hull
CPT-S12°angled
elementplastic
A 80447
Thru-hull
CPT-S20°angled
elementplastic
A 80446
Thru-hull
CPT-S0°angled
elementbronze
