Viewingangleconsiderations
Asdisplaycontrastandcolorareaffectedbytheviewingangle
,Itisrecommendedthatyou
temporarilypowerupthedisplay,priortoinstallation,toenableyoutobestjudgewhichlocation
providestheoptimumviewingangle.
RefertoChapter8Technicalspecificationforviewinganglesforyourproduct.
Productdimensions
AxiomPro9and12dimensions
AxiomPro9AxiomPro12
A
299 .32mm(11.78in)358.03mm(14.1in)
B
329 .5mm(12.97in)388.5mm(15.3in)
C
186.2mm(7 .33in)246.13mm(9.69in)
D
173. 79mm(6.84in)222.8mm(8.77in)
E
33.4mm(1.31in)31.9mm(1.26in)
F
64.5mm(2.54in)64.4mm(2.54in)
G
137 .05mm(5.4in)straightconnector
117.05mm(4.61in)rightangled
connector
137.1mm(5.4in)straightconnector
117.1mm(4.61in)rightangledconnector
H
12.86mm(0 .51in)12.86mm(0.51in)
I
84mm(3.31in)89mm(3.50in)
J
201.5mm(7 .93in)straightconnector
181.5mm(7.15in)rightangledconnector
201.5mm(7.93in)straightconnector
181.5mm(7.15in)rightangledconnector
