Setting Items
Default
Value
Max.
Value
Min.
Value
Step Unit
Correction Value 0 20 -20 1 -
0106 Switch Paper Edge Detection Sensor
Specify the level for detecting the paper edge for correcting the image position along the feeding
direction.
Setting Items Selection Default Value
Tray 1
Tray 2
3-Tray LCIT: Tray 3
3-Tray LCIT: Tray 4
3-Tray LCIT: Tray 5
Bypass Tray
2-Tray LCIT: Tray 3
2-Tray LCIT: Tray 4
2-Tray LCIT: Tray 5
2-Tray LCIT: Tray 6
2-Tray LCIT: Tray 7
2-Tray LCIT: Tray 8
Extended Option Tray
Normal
High Accuracy
Normal
• Select [High Accuracy] only when blank paper is fed. Otherwise, a paper jam may occur.
Machine: Image Quality
0201 Execute Image Quality Adjustment
Execute image control or color registration adjustment manually.
The machine adjusts the image density. The time required for each process is as follows: about 1.5
minutes for [Adjust Image Density], about 5 minutes for [Density Difference: With Fd], and about 20
7. Adjustment Settings for Operators
290
